Hillside Residence — Dimensioned Plan Set
A full dimensioned floor-plan set for a modern hillside residence — six sheets covering floor plans, elevations, and sections, all annotated to ASME conventions and delivered as native CAD plus stamped PDFs, mark-up-ready for contractors. Every dimension ties back to a single source model, so a change in one place propagates everywhere.
V2 Mount Bracket — Production Release
A billet aluminum bracket taken from a rough prototype to a full production release: parametric 6061-T6 modeling, a GD&T package with tolerance stack-up on machined features, and four machining-ready drawings any shop can quote directly. Revision A is issued as the released baseline.
Turbine Impeller Series — Resin Run
Twelve translucent turbine impellers printed in high-density liquid resin at 25-micron layer resolution for a fluid dynamics test rig. Each part was post-cured, cleaned of support scarring, and dimensionally verified against the model — tight enough to swap impellers between test sessions without recalibration.
Legacy Set Standardization — 34 Sheets
A 34-sheet legacy drawing set inherited from three different drafters, rebuilt under a single drafting standard: unified templates and title blocks, double-dimensioning and annotation collisions removed, and views re-drawn where geometry no longer matched the models. Any machine shop can pick up any sheet and read it the same way.
Parametric Configurator — Bracket Family
A rules-driven configurator for a bracket family previously modeled by hand. A spec table drives the full geometry — hole patterns, fillets, material thickness — regenerating 20+ variants in seconds instead of hours, with every output landing in native CAD format ready for release.
Engineering Archive Restructure
A decade of scattered CAD files, datasheets, and revisions — 3,200+ documents across local drives, network shares, and email attachments — consolidated under one PART-####_REV-A naming convention and a three-level folder structure, mirrored to cloud storage with a verified checksum backup.
ECN Rollout — 18-Sheet Change Package
A controlled revision rollout across an 18-sheet drawing set: redlines applied, revision blocks bumped under the governing letter scheme, BOM callouts synced to updated models, and the full package re-released with a complete ECN record — every change traceable to its notice.
Drone Frame — Carbon-Fiber Nylon
End-use drone frames printed in carbon-fiber nylon over FDM — light enough for flight, stiff enough for hard landings. Parts oriented for strength across load paths, deburred and finished for hardware mounting, and dimensionally checked under inspection lamp. Final production parts, not prototypes.
